2+4 Port POE Switch

2+4 Port POE Switch – S-4FE-2UE-LD-VLAN

Network Ports:
– 4 x 10/100Mbps PoE RJ45 ports (Ports 1-4)
– 2 x 10/100Mbps RJ45 uplink ports (Ports 5-6)

Transfer Rates:
– 100Mbps Full Duplex
– 10/100Mbps Half Duplex

Network Protocols:
– IEEE 802.3i
– IEEE 802.3u
– IEEE 802.3x
– IEEE 802.3af
– IEEE 802.3at

Performance:
– Bandwidth: 1.2Gbps (non-blocking)
– Network delay: Up to 20ps at 100 to 100Mbps (64-byte packet)
– Frame filtering/transmission rates:
– 10M port: Max 14,800 pps
– 100M port: Max 148,800 pps

LED Indicators: Power, LINK/ACT, RESV, PoE indicator

PoE Pins: 1/2+ , 3/6-

Power Output:
– Maximum power per port: 30W
– Total power: 60W (with internal power adapter)

Operating Environment:
– Temperature: 0° – 40°C
– Humidity: 10% – 90% (non-condensing)

Safety Certifications: CE, ROHS, FCC, CCC
