Video Recorder Falcon Series

Secureye S-32NV-4HDS-265 Falcon Series Video Recorder

1.Video & Audio Input :-

Chipset: Hi3536
IP Video Input: 32ch
Two Way Talk: 1-ch, RCA

2.Video & Audio Output:-

HDMI : 2ch,
Resolution:4K(3840×2160)/30Hz,1920×1080/60Hz,1440×900/60Hz,1280×1024/60Hz, 1280×720/60Hz,1024×768/60Hz1CH HDMI only 1080P, the other one is up to 4K
VGA: 1ch, resolution: 1920×1080/60Hz,1440×900/60Hz,
1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz
Audio Output: 2-ch, RCA

3.Recording:-

Compression: H.265+/H.265 /H.264+/H.264
Resolution: 8MP / 5MP /4MP / 3MP /1080P /720P /D1/CIF /QCIF

4.Playback & Backup:-

Playback Resolution: 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF /QCIF
Playback Mode: Smart Playback/Normal/Time Division/ Label/ Event/ Picture
Playback
Decoding Capability: 16ch@1080P
Backup Mode: USB Device/Network/eSATA

5.Advanced Features:-

Smart Detection: Line crossing, Area Intrusion, Fast moving, Unattached Object,
Object Missing, Face Detection
Smart Playback: Face detection/Line Crossing/Are Intrution/Motion Detection
Cloud Storage: Support
Cloud Upgrade: Support

6.Network:-

Incoming Bandwidth: 256Mbps
Outgoing Bandwidth: 256Mbps
Ethernet: 1 RJ-45 10 /100/1000 Mbps self-adaptive Ethernet interface
Network Function: HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP,DHCP,
IP Filter, DDNS, FTP, P2P, ONVIF 2.6
Smart Phone: IOS(iPhone, iPad), Android(Phone, Pad)

7.Hard Disk:-

SATA: 2 SATA interface
Capacity: Up to 8TB capacity for each HDD
8 External Interface:-
USB Interface: Front panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0
RS 485: 2
Alarm In: 16-ch
Alarm Out: 4CH

9.General:-

Power Supply: AC 100~240V 30W
Power Consumption: ≤30W(without HDD)
Working Environment:0°C~+55°C / 10%~90%RH
Dimension (W×D×H): 440×452×90mm
Weight: 7.8kg
